The perfect combination of ecology and economy

EVALASTIC® EPDM
waterproofing membrane

The EPDM waterproofing membrane EVALASTIC can do more

The EVALASTIC EPDM waterproofing membrane is free of bitumen, plasticizers, and PVC. Pioneering forward looking elastomeric technology with quality and maximum performance. EVALASTIC has everything it needs to cope with any challenge and external impact. For installation in no time, in a single layer and homogeneous in material - the EVALASTIC EPDM waterproofing membrane ensures flawless flat roof waterproofing for decades.

Advantages

When it comes to EPDM, EVALASTIC is the first choice

Homogeneous waterproofing layer
Excellent eco-balance and fully recyclable
Free of bitumen, plasticizers, and PVC
High temperature resistance (-40 °C to +100 °C)
Excellent stability against chemicals and weathering
Durable and resource-saving
Ultimate waterproofing

EVALASTIC EPDM waterproofing membrane – areas of application

The EVALASTIC EPDM waterproofing membrane deserves a closer look: EVALASTIC is the only homogeneously weldable EPDM waterproofing membrane, featuring unequalled durability compared to almost any other waterproofing membrane on the market. Moreover, the integrated system, with its different product varieties and its wide range of accessories, offers perfect solutions to any flat roof project, large or small.

Flat roof waterproofing for new build and refurbishment
The waterproofing membrane for warm roofs, cold roofs, inverted roofs
Can be used on many insulation materials, bituminous membranes, unbacked rigid polystyrene foam boards...
Optimal waterproofing for varied roof geometries
Product varieties for all installation methods and flat roof configurations
Ideal basis for green roofs
Product varieties

The EPDM waterproofing membrane for any flat roof

Every flat roof is different. That is why we offer different varieties of the EVALASTIC® EPDM waterproofing membrane for a varied range of application, thus always providing you with exactly the right membrane featuring the properties you require. It goes without saying that, in the design phase, we will assist you selecting the most appropriate solution.

EVALASTIC® EPDM waterproofing membrane
  • EPDM waterproofing membrane for non-ventilated roofs (warm roofs), ventilated (double-skin) roofs (cold roofs), inverted roofs (DUO roofs)
  • With glass/polyester fleece backing and integrated fire-retardant layer

Installation method:

  • Loose laying with ballast (gravel, green roof, concrete slabs).
  • Mechanical fastening
  • Adhesive bonding
Distinctive features of our EPDM waterproofing membrane
Sealing layer thickness excluding backing (mm) 1.2 / 1.5
Membrane width with welding edge on one side (m) 1.05 / 1.55
Membrane width with welding edge on both sides (m) 1.09 / 1.59
Tape width (cm) 54 / 79
Standard length (m) 25
Fixed lengths on request
Standard colour light grey
Special colours on request

  • EPDM waterproofing membrane for non-ventilated roofs (warm roofs), ventilated (double-skin) roofs (cold roofs), inverted roofs (DUO roofs)
  • With glass/polyester fleece backing and integrated fire-retardant layer

Installation method:

  • Loose laying with ballast (gravel, green roof, concrete slabs).
  • Mechanical fastening
  • Adhesive bonding
Features
Sealing layer thickness excluding backing (mm) 1.5
Membrane width with welded edge on one side (m) 1.05 / 1.55
Tape width (cm) 54 / 79
Standard lengths (m) 25
Fixed lengths on request
Standard colour light grey / NEW: slate grey matt
Special colours on request

  • EPDM waterproofing membrane for non-ventilated roofs (warm roofs), ventilated (double-skin) roofs (cold roofs)
  • Self-adhesive waterproofing membrane
  • With glass/polyester fleece backing as well as bitumen- and solvent-free self-adhesive coating, with integrated fire-retardant layer

Installation method:

  • Direct bonding on unbacked EPS rigid foam boards.
Features
Thickness (without backing and self-adhesive coating) (mm) 1.5
Membrane width with welding edge on one side (m) 1.05
Standard length (m) 25
Fixed lengths 25
Standard colours light grey/ NEW: slate grey matt
Special colours on request

Waterproof, attractive, safe

The EPDM waterproofing membrane accessories

We offer a comprehensive range of accessories perfectly matched to the alwitra waterproofing membranes. Allowing for quicker and easier installation and stunning results. Making good things even better in every detail!

Flat roof vent

Snow guard profiles

Coated metal sheets

Paving slab support

Standing seam effect profile

Maintenance walkway tiles

VSKA self-adhesive flashing tapes

Still sceptical about synthetic materials?

EVALASTIC EPDM waterproofing membrane vs. bituminous sheets

Choosing the EVALASTIC EPDM waterproofing membrane is the absolutely right decision: faster installation, increased longevity and cleaner flat roofs. The alwitra waterproofing membrane does not contain any herbicides, in case you want to install a green roof. And you don't need a fire guard, either. Reading the signs of the time, together we can set the path for the future.

  EVALASTIC EPDM waterproofing membrane
Lifetime
  • durable
  • long service life
  • partly recyclable
Ecology
  • 100% free of bitumen, plasticizers and PVC
  • easy removal due to
    • loose laying with ballast
    • mechanical fastening
  • clean
    • no leaching of environmentally harmful substances
    • no groundwater pollution

  • quick, reliable, single-layer installation
  • the right EPDM prefabricated detail for every configuration
fire hazard
  • no fire hazard thanks to flameless hot-air welding
Mass per unit area
  • approx. 2 kg/m²
Welding
  • fast, clean homogeneous welding
  • accurate seam without bitumen bead
  • uniform welding results
Other
  • EVALASTIC with Environmental Product Declaration (EPD) and "Blue Angel"
  • resistant to root penetration
    • without addition of herbicides/root killers
    • thanks to homogeneous welding
  • ideal waterproofing for all types of green roofs (urban gardening, urban farming)
Simply EVALASTIC for simply quick installation

Installation instructions for EVALASTIC waterproofing membranes

The installation instructions show the quick and easy handling and laying of EVALASTIC EPDM waterproofing membranes on the roof. They detail the professional installation and provide many useful practical tips and tricks. Well prepared for flat roof waterproofing!

Product brochures

Further information on our EPDM waterproofing membrane

EVALASTIC constitutes a product family and an integrated system offering a wide range of options for fast, accurate and professional flat roof waterproofing. Our brochures provide detailed and practical information on the individual products. Download them here and discover the opportunities...

Get in touch

Projects

The alwitra flat roof world in references

We are always happy to receive pictures and reports of projects we have realised together with distributors, designers and, above all, roofers. Because only practical work on site can reveal the true meaning of “united on top.”. Amazing projects, showing what we can achieve together.

Complete system

From a single source

A comprehensive sophisticated waterproofing system extending from one roof edge to the other, including all accessories and all services. So, when the work starts on the roof, everything is at hand, allowing for extremely quick, accurate and safe installation. No compromises, no flaws. It's fun, it pays off, and it gives you a comfortable feeling of security.
